AMD Ryzen™ Embedded R1505G Dual Cores Processor,4 Threads / 5M Cache, 2.4 – 3.3 GHz, 25W TDP,Integrated Graphics Processor – Radeon™ Vega 3 Graphics, Dual Channel DDR4 2400, 2 x SO-DIMMs, Max 32GB, 4 x HDMI ports, supporting a maximum resolution of 4096x2160@60Hz, 2 x GbE LAN ports, Wi-Fi 802.11ac / BT4.2, ALC 269 Audio Codec, 2 x M.2 for SSD (1 x PCIe/SATA Mode, 1 x SATA Mode), 1 x Mini PCI slot, Infineon TPM onboard*, 4 x USB 2.0 (Front), 2 x USB 3.2 (Back), Headphone/microphone jack,Support VESA Mount, Onboard headers: 2 x RS232/422/485/5V/12V/RI COM ports; 2 x RS232 COM ports
Audio
| Model | ALC 269 Codec |
| Sunet | HD Audio |
Back Panel
| HDMI | 4 |
| Retea Ethernet (RJ-45) | 2 |
| USB 3.0 | 2 |
Carcasa
| Culoare | Negru |
| Dimensiune | 196.2 x 44.4 x 140 mm |
| Sloturi expansiune | Mini PCI slot |
| Suport | VESA 100x100 mm VESA 75 x 75 mm |
| Sursa | 135W External AC power adapter |
| Tip Carcasa | Smal Form Factor |
Conectivitate
| Bluetooth | 4.2 |
| LAN | 10/100/1000 Mbps |
| Wireless | 802.11ac |
Front Panel
| Audio | 1x Combo |
| USB 2.0 | 4 |
Memorie
| Compatibilitate DIMM | SO-DIMM |
| Frecventa memorie | 2400 MHz |
| Memorie inclusa | Nu |
| Memorie maxima | 32 GB |
| Sloturi memorie | 2 |
| Tip memorie | DDR4 |
| Tip sloturi memorie | SO-DIMM |
Monitor
| Monitor inclus | Nu |
Placa De Baza
| SATA III | 1 |
Procesor
| Cache | 4 MB L3 |
| Familie procesor | Ryzen Embedded |
| Frecventa procesor | 2.40 GHz |
| Frecventa turbo max | 3.30 GHz |
| Max TDP | 25 W |
| Model Procesor | R1505G |
| Nucleu | Zen |
| Numar nuclee | 2 |
| Numar procesoare | 1 |
| Numar thread-uri | 4 |
| Procesor Grafic integrat | AMD Radeon Vega 3 Graphics |
| Producator procesor | AMD |
| Socket procesor | FP5 |
| Tehnologie | 14 nm |
Recomandat
| Recomandat | Small Office |
Software
| Sistem de operare | No OS |
Stocare
| Slot M.2 | 1 x M.2 PCIe x4/SATA Mode 1 x M.2 SATA Mode |
| Stocare inclusa | Nu |
Unitate optica
| Unitate optica | Nu are unitate optica integrata |
Video
| Familie placa video | Radeon |
| Model placa video | Vega 8 |
| Producator placa video | AMD |
| Suport DirectX | 12 |
| Tip | Integrata |
