Kit videointerfon IP Hikvision DS-KIS604-S(B), pentru o singura familie, WIFI si monitor interior de 7 inch color, kitul contine: DS-KV8113-WME1 x1, DS-KH6320-WTE1 x1, 16GB TF card x1 si POE switch DS-3E0105P x1. Descriere DS-KV8113-WME1: post exterior cu un singur buton de apelare, camera video 2MP True WDR, unghi vizualizare: Horizontal: 129° Vertical: 75°, vizualizare pe timp de noapte IR maxim 3 metri; comunicare audio bidirectionala; cititor de card incorporat pentru carduri Mifare. Descriere DS-KH6320-WTE1: monitor LCD 7 inch, rezolutie ecran 1024 × 600; design modern; Conectivitate: Retea wireless: Wi-Fi 802.11b/g/n, comunicare audio video bidirectionala; memorare poze si mesaje pe card, vizualizare live a posturilor de exterior sau a camerelor de supraveghere. Descriere switch DS-3E0105P: Switch cu 4 porturi POE fara management, buget PoE 58W, se pot conecta pana la 4 echipamente.
Caracteristici generale
| Alimentare | 12V DC - PoE (802.3af) |
| Altele | Continut Kit: Post videointerfon: 1x DS-KH6320-WTE1 Modul camera: 1x DS-KV8113-WME1 Switch PoE: 1x DS-3E0105P Card TF 16 GB |
| Audio | Microfon audio si difuzor incorporat |
| Camera | 2 MP 129 grade |
| Card memorie | 16 GB |
| Cartela de acces | Carduri Mifare |
| Compatibilitate | The device is fully configurable via the iVMS4200 software In addition, the device has the ability to work with the Hik-Connect application on mobile devices |
| Compresie video | H.264 |
| Culoare | Negru - Gri |
| Dimensiuni | Post videointerfon: 200 x 140 x 25 mm Modul camera: 174 x 91 x 30 mm Switch: 105 x 86 x 28 mm |
| Ecran | 7 inch, capacitiv, tactil Rezolutie: 1024 x 600 pixeli |
| Greutate | Post videointerfon: 0.33 kg Modul camera: 0.34 kg Switch: 0.2 kg |
| Interfata | 1x RJ-45 10/100 Mbps auto-adaptiv 1x RS-485 |
| LED indicator | Switch: Power, PoE Max, Link/Act, PoE |
| Material | Aluminiu |
| Metoda detectie | Citeste carduri Mifare 13.56 MHz |
| Protectie | IP65 |
| Putere consumata | Post videointerfon: 6 W Modul camera: 10 W Switch: 35 W |
| Stocare | 128 MB |
| Temperatura functionare | Post videointerfon: -10 °C ... 55 °C Modul camera: -40 °C ... 53 °C Switch: -10 °C ... 55 °C |
| Tip | Kit post videointerfon |
| Wireless | IEEE 802.11 b/g/n |
Componente
| Centrala de alarma | Post videointerfon: 8x Intrari alarma Modul Camera: 4x intrari alarma |
