DS1520+ | NAS Office to Corporate Data Center | 3.5" SATA(III) X 5 or 2.5'' SATA/SSD x5 | 2 x m.2 2290 NVMe | USB 3.0 port X2 | eSATA X 2 | LAN : Gigabit X 4 | Max Capacity (Internal HDD): 108TB | Max Supported IP Camera: 40 (2 licente incluse) | RAID SHR/JBOD/0/1/5/6/10 | CPU: 2.0 GHz, Dual Core | RAM Size: 8 GB DDR4 (Expandable, up to 8GB)
Caracteristici generale
| Accesorii incluse | Cabluri retea, Cablu alimentare, Manual de utilizare |
| Alimentare | 100 V to 240 V AC |
| Caracteristici | Ventilatoare: 2x 92 mm |
| Dimensiuni | 166 x 230 x 223 mm |
| Greutate | 2.26 kg |
| Nivel zgomot | 20.8 dB(A) |
| Putere consumata | 36.67 W |
Hardware
| Camere IP suportate | 40 |
| Form Factor | Tower |
| Frecventa procesor | 2.0 GHz |
| Licente supraveghere incluse | 2 |
| Memorie RAM | 8 GB (4 GB + 4 GB) DDR4 |
| Model Procesor | Intel Celeron J4125 |
| Nuclee procesor | 4-core 2.0 (base) / 2.7 (burst) GHz |
Porturi
| eSATA | 2 |
| USB 3.0 | 2 |
RAID
| JBOD | Da |
| RAID 0 | Da |
| RAID 1 | Da |
| RAID 10 | Da |
| RAID 5 | Da |
| RAID 6 | Da |
Retea
| Interfata LAN | 4x RJ 45 |
| Viteza transfer LAN | 10/100/1000 Mbps |
Stocare
| Bay-uri HDD | 5 |
| Capacitate maxima HDD | 108 TB |
| Numar HDD suportat | 5 x HDD + 2 x M.2 2280 NVME |
| Tip HDD suportat | HDD + M.2 2280 NVME |
