AMD B450 | SAM4 | MicroATX | 1xPCI-Express 2.0 1x | 1xPCI-Express 2.0 16x | 1xPCI-Express 3.0 16x | 2xM.2 | DDR4 | 4400/3533/3466/3200/3000/2800/2666/2400/2133 MHz | Memory slots 4 | 1xHDMI | 1xDisplayPort | 2xUSB 2.0 | 1xUSB type C | 5xUSB 3.2 | 1xPS/2 | 1xOptical S/PDIF | 1xRJ45 | 5xAudio port | USB 2.0 | USB 3.2 | Serial | SATA 3.0 | Video Depending on CPU | Audio | LAN Gigabit | RAID SATA 0, 1, 10
Conectivitate
| Audio jacks | 5 |
| Conectori speciali | 1x BIOS FlashBack Button |
| DisplayPort | 1 |
| HDMI | 1 |
| Iesire optica S/PDIF | 1 |
| PS/2 Combo Mouse/Tastatura | 1 |
| RJ-45 | 1 |
| Suport audio | 7.1 |
| USB 2.0 | 2 |
| USB 3.0 | 4 |
| USB 3.1 tip A | 1 |
| USB 3.1 tip C | 1 |
General
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Chipset audio | Realtek ALC S1200A |
| Chipset retea | Realtek RTL8125B 2.5Gb Ethernet |
| Interfata grafica | PCI Express x16 3.0 |
| NGFF (M.2) | 2x M.2 (2242/2260/2280) |
| Placa audio integrata | 7.1 Audio with Realtek ALC S1200A |
| Placa retea integrata | 10/100/1000/2500 Mbps |
| Placa video integrata | Necesita procesor cu tehnologia AMD Radeon Vega Graphics |
| RAID | 0, 1, 10 |
| Recomandat Gaming | Da |
| SATA III | 4 |
Memorie
| Capacitate maxima memorie RAM | 128 GB |
| Frecvente suportate | 4400(O.C)/3533(O.C)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz |
| Model memorie | DDR4 |
| Sloturi memorie | 4 |
| Tehnologie | Dual channel |
Procesor
| Chipset | B450 |
| CPU Socket | AM4 |
| Procesoare suportate | AMD 3rd Gen Ryzen/ 2nd Gen Ryzen/ 1st Gen Ryzen/ 7th Gen A-series/ Athlon X4 |
| Producator chipset | AMD |
Sloturi
| Multi-GPU CrossfireX | Suporta AMD 2-Way CrossFireX |
| PCI Express 2.0 | 1 (x4) |
| PCI Express 3.0 | 1 (x16) |
| PCI Express x1 | 1 |
Specificatii Fizice
| Dimensiuni (L x l, cm) | 24.4 x 24.4 cm |
| Format | mATX |
