MB AMD X570 SAM4 MDTX/ROG CROSSHAIR VIII IMPACT ASUS AU_ROG CROSSHAIR VIII IMPACT
Conectivitate
| Bluetooth | Bluetooth 5.0 |
| Clear CMOS | 1 |
| Iesire optica S/PDIF | 1 |
| RJ-45 | 1 |
| Suport audio | 5.1 |
| USB 3.0 | 2 |
| USB 3.1 tip A | 5 |
| USB 3.1 tip C | 1 |
| Wireless | Wi-Fi 802.11 a/b/g/n/ac/ax Supporting 2.4/5 GHz Dual-Band |
General
| Chipset audio | ROG SupremeFX |
| Chipset retea | Intel I211AT |
| Interfata grafica | PCI Express x16 4.0 |
| NGFF (M.2) | 2 |
| Placa audio integrata | 7.1 Audio with ROG SupremeFX |
| Placa retea integrata | 10/100/1000 Mbps |
| Placa video integrata | Necesita procesor cu tehnologia AMD Radeon Vega Graphics |
| RAID | 0, 1, 10 |
| Recomandat Gaming | Da |
| SATA III | 4 |
Memorie
| Capacitate maxima memorie RAM | 64 GB |
| Frecvente suportate | 4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz |
| Model memorie | DDR4 |
| Sloturi memorie | 2 |
| Tehnologie | Dual channel |
Procesor
| Chipset | X570 |
| CPU Socket | AM4 |
| Procesoare suportate | AMD AM4 Socket Ryzen 2000/3000 Series |
| Producator chipset | AMD |
Sloturi
| Header USB 3.0 | 1 (suport 2 USB 3.0) |
| PCI Express 4.0 | 1 (x16) |
Specificatii Fizice
| Format | mDTX |
