MB Z590 S1200 ATX/Z590 WIFI GUNDAM EDITION ASUS AU_Z590 WIFI GUNDAM EDITION
Conectivitate
| Audio jacks | 5 |
| Bluetooth | 5.0 |
| DisplayPort | 1 |
| HDMI | 1 |
| Iesire optica S/PDIF | 1 |
| PS/2 Combo Mouse/Tastatura | 1 |
| RJ-45 | 1 |
| Suport audio | 7.1 |
| Thunderbolt | Suport Thunderbolt 4 prin Tip-C |
| USB 2.0 | 2 |
| USB 3.2 Gen 2x2 tip A | 1x USB 3.2 Gen2x2 Type-C |
| USB 3.2 Gen1 tip A | 2 |
| USB 3.2 Gen2 tip A | 2 |
| Wireless | 2x2 Wi-Fi 802.11 a/b/g/n/ac/ax |
General
| BIOS | 192 (128+64) Mb Flash ROM, UEFI AMI BIOS |
| Chipset audio | Realtek ALC S1200A |
| Chipset retea | Intel I225-V 2.5Gbps LAN |
| Interfata grafica | PCI Express x16 4.0 |
| NGFF (M.2) | 3 |
| Placa audio integrata | 7.1 Audio with Realtek ALC S1200A |
| Placa retea integrata | 10/100/1000/2500 Mbps |
| Placa video integrata | Necesita procesor cu tehnologia Intel HD Graphics |
| RAID | 0, 1, 5, 10 |
| Recomandat Gaming | Da |
| SATA III | 6 |
Memorie
| Capacitate maxima memorie RAM | 128 GB |
| Frecvente suportate | 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz |
| Model memorie | DDR4 |
| Sloturi memorie | 4 |
| Tehnologie | Dual channel |
Procesor
| Chipset | Z590 |
| CPU Socket | 1200 |
| Procesoare suportate | Intel 11th Generation Core/Pentium/Celeron Intel 10th Generation Core/Pentium/Celeron |
| Producator chipset | Intel |
Sloturi
| Header USB 3.0 | Da |
| PCI Express 3.0 | 1 (x4) |
| PCI Express 4.0 | 1 (x16) |
| PCI Express x1 | 2 |
Specificatii Fizice
| Dimensiuni (L x l, cm) | 30.5 x 24.4 cm |
| Format | ATX |
