Intel C236 | LGA1151 | CPU's Xeon DP | Maximum number of CPUs 1 | ATX | 2xPCI-Express 8x | 1xPCI-Express 16x | 1xPCI | 1xM.2 | DDR4 | 2133 MHz | Memory features UDIMM | Memory slots 4 | 1x15pin D-sub | 2xUSB 2.0 | 2xUSB 3.0 | 1xPS/2 | 5xRJ45 | SAS | USB 2.0 | USB 3.0 | Serial | SATA 3.0 | Video | LAN Gigabit | RAID SATA 0, 1, 5, 10
Caracteristici
| Audio integrat | Fara |
| Controler SAS | ASUS PIKE II 3008-8i |
| Controler SATA | C236 |
| Retea integrat | 4 x Intel I210AT + 1 x Mgmt LAN |
| SAS | Da |
| SATA-III | 8 |
| Suport M.2 | 1 |
| Suport RAID | 0, 1, 5, 10 |
| Video integrat | Aspeed AST2400 cu 32MB VRAM |
Chipset
| Model | C236 |
| Producator | Intel |
Conectori Back Panel
| PS/2 Combo | 1 |
| RJ-45 | 4 |
| USB 2.0 | 2 |
| USB 3.0 | 2 |
| VGA | 1 |
General
| Format | ATX |
| Procesoare suportate | 1 |
| Socket | 1151 |
Memorii Suportate
| DIMM | UDIMM |
| Frecvente suportate | 2400 /2133 MHz |
| Memorie maxima | 64 GB |
| Numar sloturi | 4 |
| Tip memorie | ECC, non-ECC |
| Tip RAM | DDR 4 |
Sloturi
| PCI | 1 |
| PCI Express 3.0 x16 | 1 |
| PCI Express 3.0 x8 | 2 |
